Baffle Arrays
Sound Absorbing Ceilings




Ascend Acoustic Baffles
Peaks Array
Elevated angles lead the eye to new heights.
Cella Acoustic Baffles
Intersect Array
Straight and true like the marksman’s arrow hitting the target.
Tilde Acoustic Baffles
Waves Array
Elegant as the puffin carried along the coastal breeze.
Vice Acoustic Baffles
Vivid and punctuated to make a bold statement.
Pleasing to the eyes and ears. Be captivated by the beauty of real wood and stunned to silence by the unparalleled acoustic absorption. Flex your creative impulse with shape, pattern and texture. Baffle shapes are available in modular kit options providing you flexibility for visual designs.
Now Available with Integrated Lighting!
Illuminate your array and remove the clutter with incorporated Rensa Lit Baffle indirect lighting options.
Core Options
Core Material | RF | LR |
---|---|---|
Low VOC CDPH 1350 Compliant | ||
Humid Environments Moisture Resistant | ||
Price | $$$ | $$ |
Superior Acoustics | ||
Fire Rating ASTM E-84, Class A | ||
Thickness | ||
1″ | RFR25 | LRL25 |
1 ½” | RFR38 | LRL38 |
2″ | RFR51 | LRL51 |
Specifications
Material
Engineered material constructed of 2mm thick micro-perforated multi-ply surfaces with acoustically absorptive fibrous core.
Face Options
- 715+ Wood Species/Slice/Grade combinations.
- Custom Paint Colors. We match any paint, Pantone, and more.
Finish Options
- Custom Stains for Wood Veneers.
- Clear or Tinted Catalyzed Lacquer.
- Clear or Tinted Ulti-Matte™ Flat Varnish.
Weight
- BA-LRL25 (1” thick LR Core) 2.0 lbs/ft²
- BA-LRL38 (1½” thick LR Core) 3.0 lbs/ft²
- BA-LRL51 (2” thick LR Core) 3.5 lbs/ft²
- BA-RFR25 (1” thick RF Core) 2.0 lbs/ft²
- BA-RFR38 (1½” thick RF Core) 3.0 lbs/ft²
- BA-RFR51 (2” thick RF Core) 3.5 lbs/ft²
Fire Performance
Baffles contain either a non-combustible rockwool or fiberglass core. A thin (less than .025 inches) layer of veneer, paint, or film finish is applied. Baffles can be used in Class A environments (IBC Chapter 8 Section 803).
Accessories
Hanging kits to be ordered separately.
Leed Credits
-
LR RF
MRc4 Recycled Content
- LR Series – 21% pre-consumer
- RF Series – 30% post-consumer
- LR RF BDCv4 EQ Acoustic Performance
- LR RF EQ 4.4 Low Emitting Materials
- LR RF Material Ingredient Disclosure – Option 1
Downloadable Documents
Visit the Document Resources page for all downloadable documents.
