Lino Acoustic Planks unlock new, simpler, and more effective ways to combine exceptional acoustic control with genuine wood, providing the appearance of timber planks.
The handful of other acoustic plank systems on the market are prohibitively complex, require wide reveals between planks, a large plenum space, and a blanket of acoustic insulation held in place by a supportive layer of fabric.
Although they may appear simply as natural timber planks, the highly engineered construction of Lino Acoustic Planks results in unprecedented physical and acoustic properties.
Lino Acoustic Planks have no such limitations, enabling both unfettered design freedom and unmatched sound suppression.
Traditional acoustic planks rely on their reveals to allow sound energy to flow past them into the backloaded acoustic material. Reveals are not a factor in the sound absorption mechanics of Lino Planks. Consequently, they’re the only acoustic planks that offer the option of tight, closed, or open reveals — with no compromise in acoustic performance.
The exceptional adaptability of Lino Planks is because the planks themselves actually absorb sound, whereas other “acoustic planks” are simply normal planks, acting as visual barriers for the real sound absorbing components located behind them.
Since Lino Planks have no plenum or cavity backspace requirements they can be directly mounted to the ceiling (or wall). Due to their light weight and exceptional strength, they can be easily suspended from traditional ceiling grids, without needing extra provisions for the additional weight and warping potential associated with traditional acoustic planks.
A groundbreaking method of sound absorption that increases effectiveness as noise levels rise. The result is a more comfortable, natural feeling environment.
The reason why Lino Acoustic Planks are remarkably stronger, more stable, and weigh significantly less than other acoustic planks.
Lino Planks are the industry’s most sound absorbent acoustic planks. They provide measurably better performance without the need for insulation backloading of open reveals.
Lino Acoustic Planks are the only planks with a guarantee to perform as well in real-world installations as they do in their laboratory tests.
Lino Planks can be mounted directly to a ceiling or attached to a grid using a variety of easy-to-install mounting hardware.
Twist clips are designed for plank systems with open reveals of 1” or greater. The twist clips attach easily to the back of the planks and provide a quick, secure, and visually clean installation.
For ceiling planks with tight reveals, Plank Clips are the recommended hardware fastener. The Plank Clips impale securely onto a plank’s edge then fasten to the suspended grid using a self-tapping screw.
For direct mounting to ceilings, it’s recommended that Plank Clips be fastened to a pre-installed 15/16” hat channel. In certain instances, Plank Clips can be anchored directly into drywall using wide-thread drywall screws.
| ITEM | DESCRIPTION | STANDARD WIDTHS (nominal) |
STANDARD LENGTHS (nominal) |
NRC | CAC | FIRE CLASS |
|---|---|---|---|---|---|---|
| LR PANEL SERIESExcellent Acoustic Performance • Lower Price Point vs. RF Series • Antimicrobial & Moisture Resistant Properties | ||||||
| PL-LRM25 | 1″ Thick Acoustic Wood Planks | 6″ 8″ 12″ | 96″ 120″ | .80 | 39 | A |
| PL-LRM51 | 2″ Thick Acoustic Wood Planks | 6″ 8″ 12″ | 96″ 120″ | .95 | 39+ | A |
| RF PANEL SERIESSuperior Acoustic Performance • CDPH1350 Compliant (low VOC) | ||||||
| PL-RFM19 | 3/4″ Thick Acoustic Wood Planks | 6″ 8″ 12″ | 96″ 120″ | .70 | 43 | A |
| PL-RFM25 | 1″ Thick Acoustic Wood Planks | 6″ 8″ 12″ | 96″ 120″ | .90 | 46 | A |
| PL-RFM38 | 1 1/2″ Thick Acoustic Wood Planks | 6″ 8″ 12″ | 96″ 120″ | .95 | 46+ | A |
| PL-RFM51 | 2″ Thick Acoustic Wood Planks | 6″ 8″ 12″ | 96″ 120″ | 1.00 | 46+ | A |
| Custom plank widths and lengths available. | ||||||
Acoustic Planks consisting of a fully sealed, sound insulated, resonant cavity overlayed with a 2mm thick micro-perforated multi-ply surface.
• 715+ Wood Species/Slice/Grade combinations
• Custom Paint Colors in a variety of sheens
• Custom Stains for Wood Veneers
• Clear or Tinted Catalyzed Lacquer
• Clear or Tinted Ulti-Matte™ Flat Varnish
PL-LRM19 / PL-RFM19 (¾” thick) 1.4 lbs/ft²
PL-LRM25 / PL-RFM25 (1” thick) 1.8 lbs/ft²
PL-LRM38 / PL-RFM38 (1½” thick) 2.2 lbs/ft²
PL-LRM51 / PL-RFM51 (2” thick) 2.6 lbs/ft²
Lino Planks contain either a non-combustible rockwool or fiberglass core. A thin (less than .025 inches) layer of veneer, paint, or film finish is applied. Lino Planks can be used in Class A environments (IBC Chapter 8. Section 803).
Grids and hat channels to be ordered separately.
LRRFMRc4 Recycled Content
LR Series – 21% pre-consumer
RF Series – 30% post-consumer
LRRFBDCv4 EQ Acoustic Performance
LRRFEQ 4.4 Low Emitting Materials
LRRFMaterial Ingredient Disclosure – Option 1
